12 pages of plans, instructions, and templates for the Kerfing Plane built on the Nic Taylor Woodworking YouTube Channel. Plans include detailed instruction, high resolution pictures, measurements, and printable templates. The Kerfing Plane detailed in these plans is built using hardware from Bad Axe Tool Works, but can be easily modified for other hardware.
10x12 Timber Frame Reference Plans
Adding product to your cart
When you download these reference plans you will receive detailed drawings of the 10x12 frame built in the Tiny Timber Frame Workshop YouTube series. These plans include an exploded view of the frame and section frame views. The reference plans also have individual piece drawings that show each cut on every timber and a full timber cut list to provide an idea of how much lumber goes into a small timber frame structure.
These plans are reference plans only and not intended for actual construction.
